LED TECHNOLOGY

26500 sqm

illuminated area

Features

  • Galvanised metalworks
  • 80 μm powder coating finishing
  • High efficiency Italian made LED heads powered at 48V
  • Plug & play, colour coded cables and connectors
  • Circuit breakers to power up LED heads 1 every 2 floodlights complete with single protection
  • General MCB for electrical protection against overload
  • Specific permanent magnet alternator full DC
  • Fully bunded tank, 110%
  • Certified wind stability up to 110km/h
  • On board levels for guidance during stabilisation
  • Light bar electric tilt operation over 90° radius
  • Light bar electric rotation operation over 300°
  • Heavy duty mine spec. trailer complete with front jockey wheel
  • 4 heavy duty hydraulic extendable stabilisers
  • Full hydraulic mast with 2 step operations
  • Automatic safety PIN to block the mast before raising up to 10m
  • Black rubber chain to avoid damage during tower operation
  • 2 big side doors for easy maintenance
  • Wheel nut indicators
  • Safety 2 hands operation switch
  • Full electrical lights operation
  • Central lifting eye
  • Side forklift pockets
  • Front spare wheel
  • DSE L401 controller
  • Light sensor
  • Timer (included in the DSE L401)
  • Light sensor/timer switch
  • Battery switch
  • External emergency stop button
  • Internal work light complete with ON/OFF switch fitted on the frontal panel
