x-30

SEWAGE TREATMENT systems

Back

Separation and sedimentation. The Decantation Tank X-30 is a set of 3x1000L Tanks, able to separate mud, oil and hydrocarbons due to a system of filtration and sedimentation.

HOW DOES IT WORK?

The Decantation Tank X-30 is a set of 3x1000L Tanks, able to separate mud, oil and hydrocarbons due to a system of filtration and sedimentation.

The first treatment stage consists of a sedimentation basin in which a gravimetric separation process takes place. The compounds with different specific weights to water: sand, mud, gravel, settle and accumulate at the bottom of the tank, while lighter ones (oils, fat, etc) rise to the surface. The second treatment step consists of de-oiling. Due to the presence of coalescing filter oils and residual hydrocarbons, they are combined on the same filter as well as separating the waste-water.

Finally, the clean water is filtered through a fine filter element to be reused in the pressure-washer to close the circuit. The booster pump to deliver the clean water to the pressure-washer at the end.

It should be remembered that the drains must be carried out by competent and authorised companies, as this type of waste can be considered dangerous, and must be disposed of as such.
